Product Properties
- for small milling works on table and column drilling machines
- Working surface grounded
- Dovetailg guiding adjustable via gibs
Product Specifications
|
Length |
920 mm |
|
Width |
420 mm |
|
Height |
160 mm |
|
T-slot size |
10 mm |
|
Quantity of T-slots |
3 pcs. |
|
Table length |
640 mm |
|
Table width |
205 mm |
|
Max. workpiece weight |
50 kg |
|
Base width |
340 mm |
|
Base length |
270 mm |
|
Travel x-axis |
370 mm |
|
Travel y-axis |
200 mm |
|
Nonius handwheels |
0,04 mm |
|
Weight approx. |
65 kg |
