Electronic display of spindle speed settings.

The torsion-free square table ensures smooth cutting of heavy and large panels. The extractable telescopic fence is euqipped with an end stop with fine adjustment.

Aluminium fence rails come with fine adjustment and can easily and quickly be adjusted to each milling tool.

The planing unit consists of a dynamically balanced 3-knifecutterblock, in- and outfeed roller and massive anti-kickback devices.

The mortising unit is part of the standard accessories and ideal for drilling of oblong, dowel and angular holes.

Complete with scoring unit for burr-free operation of panels.

The planer tables tilt into upright position to allow for optimal and safe working conditions even when thicknessing short workpieces.

Universal combined machine CF 310 F - 2600 *

Art.Nr.: 08-1295

Zu Favoriten hinzufügen Zur Vergleichsliste hinzufügen

The CF 310 F - 2600 wood processing centre combines several applications on limited space: planing, sawing, milling and drilling. The standard equipment includes a scoring unit, four spindle speeds, a tiltable moulding spindle and many more features that make this model unique and unbeatable.

€7,728.00

incl. 20% VAT

Availability

In Stock

Deliverable in 2-3 business days

Product Properties

Powerful drive motors guarantee optimal results even at continuous operation
Square table with roller for convenient handling of large workpieces
All aluminium parts (sliding table, fences,...) are anodized
Moulding fence features aluminium fence rails on both sides incl. fine adjustment
Large, grey cast-iron moulder unit, tilts from 0° to -45°
Extractable telescopic fence with end stop and fine adjustment
Milling spindle speed on digital display allows for quick and easy readout
Solid planer fence with prism guide, tiltable from 90º to 45º
Maintenance-free 4-knife cutterblock with planer knives in HSS – 18 % quality
Solid moulding fence with dust extraction outlet 100 mm
Dynamically balanced milling spindle ensures precise running

Product Specifications

Planer
Planer width	310 mm
Table length	1600 mm
Table height	950 mm
Shaft rotation speed	4100 rpm
Cutter knives	4 pcs.
Planer shaft diameter	95 mm
Planer fence	1100 x 150 mm
Fence tiltable	90° bis 45°
Max. cutting depth	5 mm
Motor power output S₁ 100%	2,2 kW (3,0 HP)
Motor power input S₆ 40%	3,0 kW (4,0 HP)
Thicknesser
Table length	750 / 930* mm
Working width	305 mm
Working thickness, min/max.	5 - 230 mm
Max. cutting depth	5 mm
Feed speed	6 m/min
Dust extraction outlet	100 mm
Mortising unit
Table size	450 x 190 mm
Westcott drill chuck	0 - 16 mm
Max. drill depth	125 mm
Drill width	175 mm
Height adjustment	115 mm
Circular saw
Table size	1300 x 380 mm
Table height	950 mm
Table extension	310 x 350 mm
Square table with roll	880 x 580 mm
Sliding table	2600 x 270 mm
Cutting length	2600 mm
Max. sawblade diameter	315 x 30 mm
Max. cutting height 90° / 45°	100 / 80 mm
Cutting width on rip fence	630 mm
Speed main sawblade	4500 rpm
Speed scoring sawblade	8500 rpm
Scoring sawbalde	90 x 20 mm
Dust extraction outlet	95 mm
Motor power output S₁ 100%	3,0 kW (4,0 HP)
Motor power input S₆ 40%	4,2 kW (5,7 HP)
Spindle moulder
Spindle diameter	30 mm
Height adjustment	125 mm
Spindle tiltable	0° to -45°
Table opening	80 / 110 / 150 / 200 mm
Working length of spindle	110 mm
Max. tool diameter	180 mm
Spindle speed	1800 / 3000 / 6000 / 9000 rpm
Dust extraction outlet	100 mm
Motor power output S₁ 100%	2,8 kW (3,8 HP)
Motor power input S₆ 40%	3,9 kW (5,3 HP)
Voltage	400 V
Machine dimension (W x D x H)	2600 x 2700 x 1280 mm
Weight approx.	675 kg
